6 Handling RS232
© Nortec Electronics 2018 25
NORTEC
2014-15 UL60 V 1.0 16.06.15
SN: 160001
--------------------------------
DATE: 17.06.15
BATTERY NO:
OPERATOR NO:
NOM. VOLTAGE: 24.00 V
RATED CAP: 006.0 Ah
PROGRAM: 020
NiCd battery (manufacturer inde-
pendent)
DISCHARGE
--------------------------------
PROGRAM START 12:33:58
VOLTAGE = 27.19 V
--------------------------------
P020:S1: 12:56:16
DISCHARGE
VOLTAGE = 26.18 V
...
V
30 150
28.0
20.0
24.0
Second file
The second file .csv (comma separated file) can be used in Excel or OpenOffice. This file contains
the measurements:
Z; U; I
1;22.34;-25.03
1;20.28;-25.00
2;22.27; 12.51
2;25.44; 12.49
2;25.73; 12.50
The column Z means cycle, followed by voltage and current. This data are recorded 1 × per min-
ute.
The filename is built as follows:
1 letter for the year
2 number for the month
2 number for the day
2 number for the hour
1 number for the ten’s place of a minute
The files contain as well date and time in their attributes.
