6 Handling Functions of printer programs
© Nortec Electronics 2018 31
As long as you hear a beep during cell measurement the cell is ok. The following cell testing starts
after a valid measurement took place. The cell voltage is shown on display and will be printed at
the same time.
In case the cell voltage is under 1.50 V (final voltage of a NiCd-cell) the following sign * will be
printed in front of the value. These values may not be changed. For SAFT batteries between 1.50
V and 1.55 V the sign ¤ will be prefixed, becaused for VO/VP/VHP/VXP-batteries 1.50 V are re-
quired. For other battery manufacturer between 1.50 V and 1.55 V as well the sign * will be pre-
fixed. A cell voltage without sign * does not mean, that the battery meets the requirementsis.
There are batteries which requires 1.58 V
In case no single cells measurements have taken place the print lines CELL 01 to CELL xx and so
on... will not be indicated.
If within a printer program data retrieval is not answerd the device switches to the next request
within 30 seconds and finally back to the program routine.
Cell voltage recording
====================================
COPYRIGHT
NORTEC
2014-15 UL60 V1.0 16.06.15
SN: 160 001
------------------------------------
DATE: 23.06.15
BATTERY NO: 12345
OPERATOR NO: 0002
NOM. VOLTAGE: 24.00 V
RATED CAP: 004.0 Ah
PROGRAM: 420
NiCd battery (manufacturer independent)
Maintenance
------------------------------------
PROGRAM START 08:42:24
VOLTAGE = 26.66 V
------------------------------------
P420:S1: DISCHARGE 1 08:42:24
VOLTAGE = 25.91 V
CURRENT = 04.01 A
CAPACITY = 000.4 Ah
= 010.0 %
TIME = 006 MIN
------------------------------------
* CELL 01: 1.292 V
* CELL 02: 1.291 V
* CELL 03: 1.294 V
------------------------------------
