8 Program selection Battery data entry
44 © Nortec Electronics 2018
For determination of the maximum currents the capacity of the battery has to be indicated in Ah.
20: NiCd battery (manufacturer independent)
P420: Please enter parameter:
RATED CAP: 000.0 Ah
After entering of the capacity confirm with the start menu is shown on the dispay.
20: NiCd battery (manufacturer independent)
Program: Maintenance
Start: P=with print =without print
Entering or you will return to a mask where
Battery type and treatment can again be selected.
Entering starts the testing routine with discharging with 1 hour current as the first
step for 6 minutes. Enter to request a printed record.
Enter the following details
battery number
user number
and confirm with .
Enter starts a testing routine after battery number and user number have been
given in. Confirm by pressing the key .
In case a cell tester is connected the measurement of the cell voltage of the NiCd
batteries takes place automatically.
By pressing the button again you can start a printed record in between. Pressing the red
start key once starts the recording of the measurement of the cell voltages on the positive cell
probe.
