MS51

Nov. 28, 2019 Page 14 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

trigger setting

 Standard interrupt pins INT0



and INT1



 Supports high drive and high sink current I/O

 I/O pin internal pull-up or pull-down resistor enabled in input

mode.

 Maximum I/O Speed is 24 MHz

 Enabling the pin interrupt function will also enable the wake-up

function

ESD & EFT

ESD

 HBM pass 8 kV

EFT

 > ± 4.4 kV

Latch-up

 150 mA pass
