MS51

Nov. 28, 2019 Page 199 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PnDW – Port n Pull-down Resister Control

SFR Address

Reset Value

P0DW

9AH, page 2

0000_0000 b

P1DW

9BH, page 2

0000_0000 b

P2DW

9CH, page 2

0000_0000 b

P3DW

9DH, page 2

0000_0000 b

PnDW.7

PnDW.6

PnDW.5

PnDW.4

PnDW.3

PnDW.2

PnDW.1

PnDW.0

R/W

Bit

Name

Description

7:0

PnDW.x

Pn.x pull- down enable

0 = Pn.x pull-down Disabled.

1 = Pn.x pull- down Enabled.
