MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PnUP – Port n Pull-up Resister Control

SFR Address

Reset Value

P0UP

92H, page 2

0000_0000 b

P1UP

93H, page 2

0000_0000 b

P2UP

94H, page 2

0000_0000 b

P3UP

95H, page 2

0000_0000 b

PnUP.7

PnUP.6

PnUP.5

PnUP.4

PnUP.3

PnUP.2

PnUP.1

PnUP.0

R/W

Bit

Name

Description

7:0

PnUP.x

Pn.x pull-up enable

0 = Pn.x pull-up Disabled.

1 = Pn.x pull-up Enabled.
