Nov. 28, 2019 Page 210 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

CKCON – Clock Control

SFR Address

Reset Value

CKCON

8EH, Page0

0000_0000b

PWMCKS

T1M

T0M

CLOEN

R/W

Bit

Name

Description

CLOEN

System clock output enable

0 = System clock output Disabled.

1 = System clock output Enabled from CLO pin).

Note: CLO pin decide by AUXR5.7.
