MS51

Nov. 28, 2019 Page 239 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

IP – Interrupt Priority

[1]

SFR Address

Reset Value

B8H, All pages, Bit addressable

0000_0000 b

PADC

PBOD

PT1

PX1

PT0

PX0

R/W

Bit

Name

Description

PADC

ADC interrupt priority low bit

PBOD

Brown-out detection interrupt priority low bit

Serial port 0 interrupt priority low bit

PT1

Timer 1 interrupt priority low bit

PX1

External interrupt 1 priority low bit

PT0

Timer 0 interrupt priority low bit

PX0

External interrupt 0 priority low bit

Note: IP is used in combination with the IPH to determine the priority of each interrupt source. See Table 6.2-4 Interrupt

Priority Level Setting for correct interrupt priority configuration.
