MS51

Nov. 28, 2019 Page 240 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

IPH – Interrupt Priority High

SFR Address

Reset Value

IPH

B7H, Page 0

0000_0000 b

PADCH

PBODH

PSH

PT1H

PX1H

PT0H

PX0H

R/W

Bit

Name

Description

PADC

ADC interrupt priority high bit

PBOD

Brown-out detection interrupt priority high bit

PSH

Serial port 0 interrupt priority high bit

PT1H

Timer 1 interrupt priority high bit

PX1H

External interrupt 1 priority high bit

PT0H

Timer 0 interrupt priority high bit

PX0H

External interrupt 0 priority high bit

Note: IPH is used in combination with the IP respectively to determine the priority of each interrupt source. See Table 6.2-4

Interrupt Priority Level Setting for correct interrupt priority configuration.
