MS51

Nov. 28, 2019 Page 241 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

EIP – Extensive Interrupt Priority

SFR Address

Reset Value

EIP

EFH, Page 0

0000_0000 b

PT2

PSPI

PFB

PWDT

PPWM

PCAP

PPI

R/W

Bit

Name

Description

PT2

Timer 2 interrupt priority low bit

PSPI

SPI interrupt priority low bit

PFB

Fault Brake interrupt priority low bit

PWDT

WDT interrupt priority low bit

PPWM

PWM interrupt priority low bit

PCAP

Input capture interrupt priority low bit

PPI

Pin interrupt priority low bit

C interrupt priority low bit

Note : EIP is used in combination with the EIPH to determine the priority of each interrupt source. See Table 6.2-4 Interrupt

Priority Level Setting for correct interrupt priority configuration.
