MS51

Nov. 28, 2019 Page 243 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

EIP1 – Extensive Interrupt Priority 1

SFR Address

Reset Value

EIP1

FEH, Page 0

0000_0000 b

PPWM3

PPWM2

PPWM1

PWKT

PT3

R/W

Bit

Name

Description

PPWM3

PWM3 interrupt priority low bit

PPWM2

PWM2 interrupt priority low bit

PPWM1

PWM1 interrupt priority low bit

PWKT

WKT interrupt priority low bit

PT3

Timer 3 interrupt priority low bit

Serial port 1 interrupt priority low bit

Note: EIP1 is used in combination with the EIPH1 to determine the priority of each interrupt source. See Table 6.2-4 Interrupt

Priority Level Setting for correct interrupt priority configuration.
