MS51

Nov. 28, 2019 Page 244 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

EIPH1 – Extensive Interrupt Priority High 1

SFR Address

Reset Value

EIPH1

FFH, Page 0

0000_0000 b

PPWM3H

PPWM2H

PPWM1H

PWKTH

PT3H

PSH

R/W

Bit

Name

Description

PPWM3H

PWM3 interrupt priority high bit

PPWM2H

PWM2 interrupt priority high bit

PPWM1H

PWM1 interrupt priority high bit

PWKTH

WKT interrupt priority high bit

PT3H

Timer 3 interrupt priority high bit

PSH

Serial port 1 interrupt priority high bit

Note: EIPH1 is used in combination with the EIP1 to determine the priority of each interrupt source. See Table 6.2-4 Interrupt

Priority Level Setting for correct interrupt priority configuration.
