MS51

Nov. 28, 2019 Page 245 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

EIP2 – Extensive Interrupt Priority 2

SFR Address

Reset Value

EIP2

CEH, Page 2

0000_0000 b

PSC2

PSC1

PSC0

R/W

Bit

Name

Description

PSC2

SC2 / UART4 interrupt priority low bit

PSC1

SC1 / UART3 interrupt priority low bit

PSC0

SC0 / UART2 interrupt priority low bit

Note: EIP2 is used in combination with the EIPH2 to determine the priority of each interrupt source. See Table 6.2-4 Interrupt

Priority Level Setting for correct interrupt priority configuration.
