MS51

Nov. 28, 2019 Page 277 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PnM1 – Port Mode Select 1

SFR Address

Reset Value

P0M1

B1H, Page 0

1111_1111 b

P1M1

B3H, Page 0

1111_1111 b

P2M1

89H, Page 2

0011_1111 b

P3M1

ACH, Page 0

1111_1111 b

PnM1.7

PnM1.6

PnM1.5

PnM1.4

PnM1.3

PnM1.2

PnM1.1

PnM1.0

R/W

Bit

Name

Description

7:0

PnM1[7:0]

Port 0 mode select 1
