CAPCON1 – Input Capture Control 1
Register
SFR Address
Reset Value
CAPCON1
93H, Page 0
0000_0000b
7
6
5
4
3
2
1
0
-
-
CAP2LS[1:0]
CAP1LS[1:0]
CAP0LS[1:0]
-
-
R/W
R/W
R/W
Bit
Name
Description
7:6
-
Reserved
5:4
CAP2LS[1:0]
Input capture 2 level select
00 = Falling edge.
01 = Rising edge.
10 = Either rising or falling edge.
11 = Reserved.
3:2
CAP1LS[1:0]
Input capture 1 level select
00 = Falling edge.
01 = Rising edge.
10 = Either rising or falling edge.
11 = Reserved.
1:0
CAP0LS[1:0]
Input capture 0 level select
00 = Falling edge.
01 = Rising edge.
10 = Either rising or falling edge.
11 = Reserved.
