MS51

Nov. 28, 2019 Page 310 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

CnL – Capture Low Byte, n = 0,1,2

SFR Address

Reset Value

C0L

E4H, Page 0

0000_0000 b

C1L

E6H, Page 0

0000_0000 b

C2L

EDH, Page 0

0000_0000 b

CnL[7:0]

R/W

Bit

Name

Description

7:0

CnL[7:0]

Input capture n result low byte

The CnL register is the low byte of the 16-bit result captured by input capture n.
