MS51

Nov. 28, 2019 Page 345 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PWM0FBD – PWM Fault Brake Data

SFR Address

Reset Value

PWM0FBD

D7H, Page 0

0000_0000 b

FBF

FBINLS

FBD5

FBD4

FBD3

FBD2

FBD1

FBD0

R/W

Bit

Name

Description

FBF

Fault Brake flag

This flag is set when FBINEN is set as 1 and FB pin detects an edge, which matches FBINLS

(PWM0FBD.6) selection. This bit is cleared by software. After FBF is cleared, Fault Brake data

output will not be released until PWM0RUN (PWM0CON0.7) is set.

FBINLS

FB pin input level selection

0 = Falling edge.

1 = Rising edge.

5:0

FBDx

PWMx Fault Brake data

0 = PWM0Cx signal is overwritten by 0 once Fault Brake asserted.

1 = PWM0Cx signal is overwritten by 1 once Fault Brake asserted.
