Nov. 28, 2019 Page 344 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PWM0CON1 – PWM Control 1

SFR Address

Reset Value

PWM0CON1

DFH, Page 0

0000_0000 b

PWMMOD[1:0]

PWMTYP

FBINEN

PWMDIV[2:0]

R/W

Bit

Name

Description

FBINEN

FB pin input enable

0 = PWM output Fault Braked by FB pin input Disabled.

1 = PWM output Fault Braked by FB pin input Enabled. Once an edge, which matches

FBINLS (PWM0FBD.6) selection, occurs on FB pin, PWM0 channel 0~5 output Fault

Brake data in PWM0FBD register and PWM6/7 remains their states. PWM0RUN

(PWM0CON0.7) will also be automatically cleared by hardware. The PWM output

resumes when PWM0RUN is set again.
