MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PWMnMD –PWMnCx Mask Data

PMD5

PMD4

PMD3

PMD2

PMD1

PMD0

R/W

Bit

Name

Description

PMDx

PWMnCx mask data

The PWMnCx signal outputs mask data once its corresponding PMENx is set.

0 = PWMnCx signal is masked by 0.

1 = PWMnCx signal is masked by 1.

Note: PMD2~5 are only for PWM0.

SFR Address

Description

Reset Value

PWM0MD

FCH, Page 0

PWM0Cx Mask Data

0000_0000 b

PWM1MD

ACH, Page 2

PWM1Cx Mask Data

0000_0000 b

PWM2MD

BCH, Page 2

PWM2Cx Mask Data

0000_0000 b

PWM3MD

CCH, Page 2

PWM3Cx Mask Data

0000_0000 b
