MS51 32K SERIES TECHNICAL REFERENCE MANUAL

PWMxMEN – PWMnCx Mask Enable, n=0,1,2,3;x=0,1,2,3,4,5

PMEN5

PMEN4

PMEN3

PMEN2

PMEN1

PMEN0

R/W

Bit

Name

Description

PMENx

PWMnCx mask enable

0 = PWMnCx signal outputs from its PWM generator.

1 = PWMnCx signal is masked by PMDx.

Note: PMEN2~5 are only for PWM0.

SFR Address

Description

Reset Value

PWM0MEN

FBH, Page 0

PWM0Cx Mask Enable

0000_0000 b

PWM1MEN

ADH, Page 2

PWM1Cx Mask Enable

0000_0000 b

PWM2MEN

BDH, Page 2

PWM2Cx Mask Enable

0000_0000 b

PWM3MEN

CDH, Page 2

PWM3Cx Mask Enable

0000_0000 b
