MS51

Nov. 28, 2019 Page 385 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

AUXR1 – Auxiliary Register 1

SFR Address

Reset Value

AUXR1

A2H , Page 0

POR: 0000 0000b,

Software reset: 1U00 0000b,

nRESET pin: U100 0000b,

Others: UUU0 0000b

SWRF

RSTPINF

HardF

SLOW

GF2

UART0PX

DPS

R/W

Bit

Name

Description

UART0PX

Serial port 0 pin exchange

0 = Assign RXD to P0.7 and TXD to P0.6 by default.

1 = Exchange RXD to P0.6 and TXD to P0.7.

Note that TXD and RXD will exchange immediately once setting or clearing this bit. User should

take care of not exchanging pins during transmission or receiving. Or it may cause unpredictable

situation and no warning alarms.
