MS51

Nov. 28, 2019 Page 386 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

AUXR2 – Auxiliary Register 2

SFR Address

Reset Value

AUXR2

A1H, Page 2

0000_0000 b

UART2TXP

UART2RXP

UART1TXP

UART1RXP

R/W

Bit

Name

Description

3:2

UART1TXP

UART1 TX pin select

00 = Reserved by default

01 = Assign UART1 TX to P1.6

10 = Assign UART1 TX to P3.6

11 = Assign UART1 TX to P1.0

1:0

UART1RXP

UART1 RX pin select

00 = Reserved by default

01 = Assign UART1 RX to P0.2

10 = Assign UART1 RX to P3.7

11 = Assign UART1 RX to P0.0
