MS51

Nov. 28, 2019 Page 400 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

SCnETURD0 – SCn ETU Rate Divider Register

SFR Address

Reset Value

SC0ETURD0

DBH, Page 2

0111_0011 b

SC1ETURD0

E3H, Page 2

0111_0011 b

SC2ETURD0

EBH, Page 2

0111_0011 b

ETURDIV[7:0]

R/W

Bit

Name

Description

7:0

ETURDIV[7:0]

LSB bits of ETU Rate Divider

The field indicates the LSB of clock rate divider.

The real ETU is ETURDIV[11:0] + 1.

Note 1: ETURDIV[11:0] must be greater than 0x004.

Note 2: SCnETURD0 has to program first, then SCnETUDR2.
