MS51

Nov. 28, 2019 Page 406 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

AUXR2 – Auxiliary Register 2

SFR Address

Reset Value

AUXR2

A1H, Page 2

0000_0000 b

UART2TXP

UART2RXP

UART1TXP

UART1RXP

R/W

Bit

Name

Description

7:6

UART2TXP

UART2 TX pin select

00 = Reserved by default

01 = Assign UART2 TX to P0.3

10 = Assign UART2 TX to P3.0

11 = Reserved

5:4

UART2RXP

UART2 RX pin select

00 = Reserved by default

01 = Assign UART2 RX to P0.4

10 = Assign UART2 RX to P1.7

11 = Reserved
