MS51

Nov. 28, 2019 Page 407 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

AUXR3 – Auxiliary Register 3

SFR Address

Reset Value

AUXR3

A2H, Page 2

0000_0000 b

UART4TXP

UART4RXP

UART3TXP

UART3RXP

R/W

Bit

Name

Description

7:6

UART4TXP

UART4 TX pin select

00 = Reserved by default

01 = Assign UART4 TX to P2.3

10 = Reserved

11 = Reserved

5:4

UART4RXP

UART4 RX pin select

00 = Reserved by default

01 = Assign UART4 RX to P2.2

10 = Reserved

11 = Reserved

3:2

UART3TXP

UART3 TX pin select

00 = Reserved by default

01 = Assign UART3 TX to P1.2

10 = Assign UART3 TX to P1.5

11 = Assign UART3 TX to P0.5

1:0

UART3RXP

UART3 RX pin select

00 = Reserved by default

01 = Assign UART3 RX to P1.1

10 = Assign UART3 RX to P2.5

11 = Assign UART3 RX to P3.4
