MS51

Nov. 28, 2019 Page 440 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

SPDR – Serial Peripheral Data Register

SFR Address

Reset Value

SPDR

F5H, Page 0

0000_0000 b

SPDR[7:0]

R/W

Bit

Name

Description

7:0

SPDR[7:0]

Serial peripheral data

This byte is used for transmitting or receiving data on SPI bus. A write of this byte is a write to the

shift register. A read of this byte is actually a read of the read data buffer. In Master mode, a write

to this register initiates transmission and reception of a byte simultaneously.
