MS51

Nov. 28, 2019 Page 455 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

ADCRH – ADC Result High Byte

SFR Address

Reset Value

ADCRH

C3H, Page 0

0000_0000 b

ADCR[11:4]

Bit

Name

Description

7:0

ADCR[11:4]

ADC result high byte

The most significant 8 bits of the ADC result stored in this register.
