MS51

Nov. 28, 2019 Page 454 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

AINDIDS1 – ADC Channel Digital Input Disconnect

SFR Address

Reset Value

AINDIDS1

99H, Page 2

0000_0000 b

P25DIDS

P14DIDS

P13DIDS

P24DIDS

P23DIDS

P22DIDS

P21DIDS

Bit

Name

Description

PnnDIDS

ADC Channel digital input disable

0 = ADC channel n digital input Enabled.

1 = ADC channel n digital input Disabled. ADC channel n is read always 0.
