MS51

Nov. 28, 2019 Page 453 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

AINDIDS0 – ADC Channel Digital Input Disconnect

SFR Address

Reset Value

AINDIDS0

F6H, Page 0

0000_0000 b

P11DIDS

P03DIDS

P04DIDS

P05DIDS

P06DIDS

P07DIDS

P30DIDS

P17DIDS

R/W

Bit

Name

Description

7:0

AINnDIDS

ADC Channel digital input disable

0 = Enabled digital input at ADC channel n.

1 = Disabled digital input at ADC channel n . ADC channel n is read always 0.
