MS51

Nov. 28, 2019 Page 459 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

ADCBAH – ADC RAM Base Address High Byte

SFR Address

Reset Value

ADCBAH

84H, Page 2

0000_0000 b

ADCBAH[3:0]

R/W

Bit

Name

Description

7:4

Reserved

3:0

ADCBAH[3:0]

ADC RAM base address (High byte)

The most significant 4 bits of RAM base address to store ADC continue sampling data.

RAM base address ADCBA[11:0] = {ADCBAH[3:0], ADCBAL[7:0]}
