ADCBAL – ADC RAM Base Address Low Byte

SFR Address

Reset Value

ADCBAL

85H, Page 2

0000_0000 b

ADCBAL[7:0]

R/W

Bit

Name

Description

7:0

ADCBAL[7:0]

ADC RAM base address (Low byte)

The least significant 8 bits of RAM base address to store ADC continue sampling data.

RAM base address ADCBA[11:0] = {ADCBAH[3:0], ADCBAL[7:0]}
