MS51

Nov. 28, 2019 Page 461 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

ADCSN – ADC Sampling Number

SFR Address

Reset Value

ADCSN

8DH, Page 2

0000_0000 b

ADCSN[7:0]

R/W

Bit

Name

Description

7:0

ADCSN[7:0]

ADC Sampling Number

The total sampling numbers for ADC continue sampling select.

Total sampling number= ADCSN[7:0] + 1
