MS51 32K SERIES TECHNICAL REFERENCE MANUAL

SP – Stack Pointer

SFR Address

Reset Value

81H, All pages

0000_0111b

SP[7:0]

R/W

Bit

Name

Description

7:0

SP[7:0]

Stack pointer

The Stack Pointer stores the scratch-pad RAM address where the stack begins. It is incremented

before data is stored during PUSH or CALL instructions. Note that the default value of SP is 07H.

This causes the stack to begin at location 08H.
