Nov. 28, 2019 Page 50 of 491 Rev 1.00

MS51 32K SERIES TECHNICAL REFERENCE MANUAL

DPL – Data Pointer Low Byte

SFR Address

Reset Value

DPL

82H, All pages

0000_0000b

DPL[7:0]

R/W

Bit

Name

Description

7:0

DPL[7:0]

Data pointer low byte

This is the low byte of 16-bit data pointer. DPL combined with DPH serve as a 16-bit data pointer

DPTR to access indirect addressed RAM or Program Memory. DPS (AUXR0.0) bit decides which

data pointer, DPTR or DPTR1, is activated.
