- 198 -
6. Maintenance
6
Push the blue lever on the new fuser unit and remove the safety stopper.
7
Hold the handle of a new fuser unit, align the fuser unit to the grooves behind
the toner cartridges, place the fuser unit into the machine.
8
Tilt back the fuser unit lock levers (c) to lock.
9
Close the output tray (b) slowly and push the center of the tray for
confirmation.
Do not touch the LED head when closing the output tray.
To Next Page
