- 358 -
11. Utility Software
13
Click [Submit].
The new settings take effect when the network function of this machine restarts.
14
Turn the machine off after this machine becomes online.
15
Connect the LAN cable to the network interface connector.
16
Connect the LAN cable to the authentication port of an authentication switch.
17
Turn the machine on.
18
Set up this machine.
Setting by Using PEAP
This section describes how to set PEAP, which is an EAP authentication type.
1
Open the Web page of this machine.
Open the Web Page of This Machine
2
Log in as the administrator.
3
Select [Admin Setup].
4
Select [Network] > [IEEE802.1X].
5
Select [Enable] from [IEEE802.1X].
6
Select [PEAP] from [EAP Type].
7
Enter a user name in [EAP User].
8
Enter a password in [EAP Password].
9
Select [Authenticate Server], and then click [Import].
10
Enter the file name of the CA certificate, and then click [OK].
Specify the certificate of the certificate authority (CA) to be used when authenticating
RADIUS server. You can import a PEM, DER, and PKCS#7 file.
11
Click [Submit].
The new settings take effect when the network function of this machine restarts.
12
Turn the machine off after this machine becomes online.
13
Connect the LAN cable to the network interface connector.
14
Connect the LAN cable to the authentication port of an authentication switch.
15
Turn the machine on.
16
Set up this machine.
