Reload Paper
41
Figure 14. Aligning the Perforation with the TOF Indicator
28. Align the top of the first print line with the TOF indicator on the
tractor by rotating the vertical position knob. For best print
quality, it is recommended that the top-of-form be set at least
one print line or more below the perforation.
NOTE: For exact positioning, press the VIEW/EJECT key to move
the last data printed to the tractor area for viewing. While in
View mode “Printer in View” displays. Press the Up or
Down Arrow keys to move the paper vertically in small
increments. Pressing the VIEW/EJECT key a second time
moves the paper back to the adjusted print position. The
key works both online and offline provided that the printer is
in View mode. (This procedure is applicable for both the
cabinet and pedestal models.)
Perforation
TOF Indicator
Vertical Position Knob
To Next Page
