XYAA6336 Service Manual 2-3
2.2.2 PR4 SR
The PR4 SR (Single Roll) packaging includes the
printer, a printer roll, ribbon cartridge, client display
support, two paper guides with two flanges, four
spacers to form 139.7 mm., 114.3 mm., 82.5 mm.
and 76.2 mm. long rolls, respectively.
Depending on the order made by the client, the
following options may be present:
A Power cord
B External power supply
C Serial interface cable
D Front insertion tray
A
B
C
D
Figure 2-3
