XYAA6336 Service Manual 8-1
Figure 8-1
• Open the machine and insert the drawer and
display drive card by following the procedure
described in Section 5.4.
• Insert the card in the slots on the base (see Figure
8-1) and then attach the connection cable to the
main board.
DISPLAY
CABLE
DRAWER
CABLE
J6
8. INSTALLING THE DRAWER
AND DISPLAY CARD OPTION
J9
