4.1 OPERATOR TEST
If the printer's front cover is closed with an operator
test LED configuration, the printer firmware release,
the setup parameters defined and the character set
defined are printed on the receipt roll.
4.2 SETUP FROM THE CONSOLE
4.2.1 Accessing this Setup Mode
The procedure to follow for accessing this Setup is
explained in the section
Setup and Adjustments
and
informs how to obtain the LED configuration for setup.
If the printer's front cover is closed (with the Setup
LED configuration) the defined setup parameters, the
functions of the keys in this mode and the title of the
first five menus will be printed as shown in the
example below:
See also the following sections:
•
Selectable Parameters
•
Selecting the Parameters
EMULATION: PR4 EMULATION PR4 SR
ROLL WIDTH: 70 mm ROLL WIDTH: 140 mm
Setup parameters defined
Functions of the keys
First menu
CONSOLE KEY FUNCTIONS:
RECEIPT NEXT ITEM
JOURNAL SELECTS THE ITEM
BIT: 8
BAUD: 9600
STOP: 1
PARITY: NONE
HANDSHAKE: DTR
NATION: CP 437
CPI: 15
CUTTER: YES
WAIT: 0.5
SI/SO: NO
EMULATION FORMAT
