Olivetti PR4 SR - Removing the Blockages Used for Transportation; Pr4

2-4Service ManualXYAA6336
Figure 2-4
2.3 REMOVING THE BLOCKAGES
USED FOR TRANSPORTATION
2.3.1 PR4
• Remove the plastic strip from the front feed slot.
• Open the front cover by turning it upwards.
• Remove the cardboard that blocks the print head.
• Close the printer cover.
