Omron CJ2H-CPU6*-EIP Series User Manual

6 Interrupts
6-16
CJ2M CPU Unit Pulse I/O Module User’s Manual
Ladder Program Example
Cyclic Task
Interrupt Task 142
Interrupt input 2
Interrupt input 2
Specifies executing
interrupt when input
turns ON.
Unmasks the
interrupt input.
The MSKS instruction is used
to specify an interrupt when the
input turns ON and then it is
used to unmask the interrupt
input.
Reset input
P_First_Cycle
2961.00
2961.01
2961.02
2961.03
2961.04
2960.04
OK output
NG output 2
NG output 3
NG output 4
NG output 1
Sensor input 1
Sensor input 1
Sensor input 2
Sensor input 2
Sensor input 3
Sensor input 3
OK output
NG output 2
NG output 3
NG output 4
2960.00
2960.00
2960.01
2960.03
2960.01 2960.03
2961.00
2961.02
2961.03
2961.04
2961.01
2960.00
2960.01
2960.03
Sensor input 1
Sensor input 2
Sensor input 3
NG output 1
!
!
!
