4 Normal I/O
CJ2M CPU Unit Pulse I/O Module User’s Manual
4-2 Normal Outputs
4
4-2-1 Overview
4-2 Normal Outputs
Normal outputs are used to output standard output signals. The output point is refreshed when the allo-
cated bit goes ON or OFF. Normal outputs are allocated to bits 00 to 05 of CIO 2961 and CIO 2963.
4-2-1 Overview
4-2-2 Flow of Operation
1
• Functions are assigned to output terminals when an
instruction (such as OUT, ORG(889), or PWM(891)) is
executed for an output bit.
2
• Execute the OUT instruction or other instructions.
• Use !OUT instructions and other immediate refreshing
version of instructions when immediate refreshing is
required.
Note: Immediate refreshing cannot be performed by the
IORF(097) instruction.
Determine the normal outputs to use.
Write the ladder program.

Omron CJ2H-CPU6*-EIP Series Specifications

General

Series	CJ2H
Ethernet/IP	Yes
Number of I/O Points	2560
Power Supply	24 VDC
USB Port	Yes
Maximum Number of mounted I/O Units	40
Maximum Number of Units	40
Power Supply Voltage	24 VDC
Operating Temperature	0 to 55 °C
Humidity	10 to 90% (non-condensing)
Shock Resistance	150 m/s²
Programming Language	Structured Text, Ladder Diagram, Function Block Diagram
EtherNet/IP Port	Yes
Built-in RS-232C Port	Yes
Vibration Resistance	10 to 57 Hz
Instruction Execution Speed	0.02 µs (basic instructions)
