8 Pulse Outputs
CJ2M CPU Unit Pulse I/O Module User’s Manual
8-11 Pulse Output Patterns
8
8-11 Pulse Output Patterns
The pulse output function of the Pulse I/O Module enables operation in Continuous Mode, for which the
number of output pluses is not specified, or in Independent Mode, for which the number of output
pulses is specified. Continuous Mode is used for speed control and Independent Mode is used for posi-
tioning.
The following operations can be performed in Continuous Mode by combining instructions.
8-11-1 Speed Control (Continuous Mode)
Starting a Pulse Output
Operation
Example
application
Frequency changes Function
Procedure
Instructions Settings
Output with
specified
speed
Changing the
speed (fre-
quency) in one
step
Outputs
pulses at a
specified fre-
quency.
SPED
(Continuous)
•Port
• Pulse + direction
• Continuous
• Target frequency
Output with
specified
acceleration
and speed
Accelerating the
speed (fre-
quency) at a
fixed rate
Outputs
pulses and
changes the
frequency at a
fixed rate.
ACC
(Continuous)
•Port
• Pulse + direction
• Continuous
• Acceleration/
deceleration rate
• Target frequency
Changing Settings
Operation
Example
application
Frequency changes Function
Procedure
Instructions Settings
Change
speed in one
step
Changing the
speed during
operation
Changes the
frequency
(higher or
lower) of the
pulse output
in one step.
SPED (Con-
tinuous)
↓
SPED (Con-
tinuous)
•Port
• Continuous
• Target frequency
Pulse frequency
Target frequency
SPED instruction executed
Time
Pulse frequency
Target frequency
ACC instruction executed.
Time
Acceleration/
deceleration
rate
Pulse frequency
Target frequency
Present frequency
SPED instruction executed
Time
