5 Quick-response Inputs

5-4

CJ2M CPU Unit Pulse I/O Module User’s Manual

Interrupt Input and Quick-response Input Detailed Settings

Note The power supply must be restarted after the PLC Setup is transferred in order to validate the quick-

response input settings.

Pulse I/O

Module No.

Input Operation

Corresponding bit

address

0 (on the right) IN00 Select Quick for IN00

to IN03 or IN10 to

IN13.

CIO 2960.00

IN01 CIO 2960.01

IN02 CIO 2960.02

IN03 CIO 2960.03

1 (on the left) IN10 CIO 2962.00

IN11 CIO 2962.01

IN12 CIO 2962.02

IN13 CIO 2962.03
