Serial Communications Section 6-1
FINS Commands The following table lists the FINS commands. Refer to the FINS Commands
Reference Manual (W227) for more details.
Host Link
communi-
cations
processing
commands
XZ ABORT (command
only)
Aborts the host link command that is currently being processed.
** INITIALIZE (com-
mand only)
Initializes the transmission control procedure of all PLCs connected to the
host computer.
IC Undefined com-
mand
(response only)
This response is returned if the header code of a command was not recog-
nized.
Type Header
code
Name Function
Type Command
code
Name Function
I/O Memory
Area Access
Commands
01 01 MEMORY AREA READ Reads consecutive data from the I/O memory area.
01 02 MEMORY AREA WRITE Writes consecutive data to the I/O memory area.
01 03 MEMORY AREA FILL Fills the specified range of I/O memory with the same
data.
01 04 MULTIPLE MEMORY AREA
READ
Reads non-consecutive data from the I/O memory area.
01 05 MEMORY AREA TRANSFER Copies and transfers consecutive data from one part of
the I/O memory area to another.
Parameter
Area Access
Commands
02 01 PARAMETER AREA READ Reads consecutive data from the parameter area.
02 02 PARAMETER AREA WRITE Writes consecutive data to the parameter area.
02 03 PARAMETER AREA FILL Fills the specified range of the parameter area with the
same data.
Program Area
Access Com-
mands
03 06 PROGRAM AREA READ Reads data from the user program area.
03 07 PROGRAM AREA WRITE Writes data to the user program area.
03 08 PROGRAM AREA CLEAR Clears the specified range of the user program area.
Execution
Control Com-
mands
04 01 RUN Switches the CPU Unit to RUN or MONITOR mode.
04 02 STOP Switches the CPU Unit to PROGRAM mode.
Configuration
Read Com-
mands
05 01 CONTROLLER DATA READ Reads CPU Unit information.
05 02 CONNECTION DATA READ Reads the model numbers of the specified Units.
Status Read
Commands
06 01 CONTROLLER STATUS READ Reads the CPU Unit’s status information.
06 20 CYCLE TIME READ Reads the average, maximum, and minimum cycle
times.
Clock Access
Commands
07 01 CLOCK READ Reads the clock.
07 02 CLOCK WRITE Sets the clock.
Message
Access Com-
mands
09 20 MESSAGE READ/CLEAR Reads/clears messages and FAL (FALS) messages.
Access Right
Commands
0C 01 ACCESS RIGHT ACQUIRE Acquires the access right if no other device holds it.
0C 02 ACCESS RIGHT FORCED
ACQUIRE
Acquires the access right even if another device cur-
rently holds it.
0C 03 ACCESS RIGHT RELEASE Releases the access right regardless of what device
holds it.
Error Access
Commands
21 01 ERROR CLEAR Clears errors and error messages.
21 02 ERROR LOG READ Reads the error log.
21 03 ERROR LOG CLEAR Clears the error log pointer to zero.
Forced Status
Commands
23 01 FORCED SET/RESET Force-sets, force-resets, or clears the forced status of
the specified bits.
23 02 FORCED SET/RESET CANCEL Cancels the forced status of all force-set and force-reset
bits.
