Omron CP1H CPU User Manual

718
PLC Setup Appendix G
2 2-2 NT Link (1:N): 1:N NT Links
2-2-1 Baud 9,600
(disabled)
38,400 (standard) Every cycle 145 00 to
07
00 hex
115,200 (high speed) 0A hex
2-2-2 NT/PC
Link Max:
Highest
unit num-
ber
0 0 Every cycle 150 00 to
03
0 hex
: :
7 7 hex
2-3 RS-232C
2-3-1 Baud 9600 bps 300 bps Every cycle 145 00 to
07
01 hex
600 bps 02 hex
1,200 bps 03 hex
2,400 bps 04 hex
4,800 bps 05 hex
9,600 bps 00 or
06 hex
19,200 bps 07 hex
38,400 bps 08 hex
57,600 bps 09 hex
115,200 bps 0A hex
2-3-2 Format
(data
length,
stop bits,
parity)
7,2,E: 7-bit
data, 2 stop
bits, even parity
7,2,E: 7-bit data, 2 stop
bits, even parity
Every cycle 144 00 to
03
0 hex
7,2,O: 7-bit data, 2 stop
bits, odd parity
1 hex
7,2,N: 7-bit data, 2 stop
bits, no parity
2 hex
7,1,E: 7-bit data, 2 stop
bits, even parity
4 hex
7,1,O: 7-bit data, 1 stop
bit, odd parity
5 hex
7,1,N: 7-bit data, 1 stop
bit, no parity
6 hex
8,2,E: 8-bit data, 2 stop
bits, even parity
8 hex
8,2,O: 8-bit data, 2 stop
bits, odd parity
9 hex
8,2,N: 8-bit data, 2 stop
bits, no parity
A hex
8,1,E: 8-bit data, 1 stop
bit, even parity
C hex
8,1,O: 8-bit data, 1 stop
bit, odd parity
D hex
8,1,N: 8-bit data, 1 stop
bit, no parity
E hex
2-3-3 Start Code Disable. Disable. Every cycle 149 12 0
Set. 1
2-3-4 Start Code 00 hex0x0000 0x0000 Every cycle 148 08 to
15
00 hex
: :
0x00FF FF hex
2-3-5 End Code Received
Bytes: Receive
specified num-
ber of bytes.
Received Bytes: Receive
specified number of
bytes.
Every cycle 149 08 and
09
00
CR,LF 10
Set End Code 01
2-3-6 Received
Bytes
256 bytes 256 bytes Every cycle 149 00 to
07
00 hex
1 byte 01 hex
: :
255 bytes FF hex
Name Default Settings When setting is read
by CPU Unit
Internal
address
Bits Settings
