Omron CP1H CPU User Manual

739
PLC Setup Appendix G
DA 0CH/DA 1CH: Analog Output Settings
SIOU Refresh: Special I/O Unit Refresh Settings
Disable SIOU Cyclic Refresh: Special I/O Unit Refresh Disable Settings
3 Analog Input 2: Use Do not use. Do not use. When power is turned
ON
77 7 0
Use. 1
3-1 Range −10 to 10 V −10 to 10 V When power is turned
ON
77 00 to
02
0 hex
0 to 10 V 1 hex
1 to 5 V 2 hex
0 to 5 V 3 hex
0 to 20 mA 4 hex
4 to 20 mA 5 hex
3-2 Use averaging Do not use. Do not use. When power is turned
ON
77 6 0
Use. 1
4 Analog Input 3: Use Do not use. Do not use. When power is turned
ON
77 15 0
Use. 1
4-1 Range −10 to 10 V −10 to 10 V When power is turned
ON
77 08 to
10
0 hex
0 to 10 V 1 hex
1 to 5 V 2 hex
0 to 5 V 3 hex
0 to 20 mA 4 hex
4 to 20 mA 5 hex
4-2 Use averaging Do not use. Do not use. When power is turned
ON
77 14 0
Use. 1
Name Default Settings When setting is read
by CPU Unit
Internal
address
Bits Settings
1 Analog Input 0: Use Do not use. Do not use. When power is turned
ON
78 7 0
Use. 1
1-1 Range −10 to 10 V −10 to 10 V When power is turned
ON
78 00 to
02
0 hex
0 to 10 V 1 hex
1 to 5 V 2 hex
0 to 5 V 3 hex
0 to 20 mA 4 hex
4 to 20 mA 5 hex
2 Analog input 1: Use Do not use. Do not use. When power is turned
ON
78 15 0
Use. 1
2-1 Range −10 to 10 V −10 to 10 V When power is turned
ON
78 08 to
10
0 hex
0 to 10 V 1 hex
1 to 5 V 2 hex
0 to 5 V 3 hex
0 to 20 mA 4 hex
4 to 20 mA 5 hex
Name Default Settings When setting is read
by CPU Unit
Internal
address
Bits Settings
1 SIOU 0 Disable. Disable. At start of operation 226 0 0
Enable. 1
2 SIOU 1 Disable. Disable. At start of operation 226 1 0
Enable. 1
: : :
:
: : :
:
Name Default Settings When setting is read
by CPU Unit
Internal
address
Bits Settings
