Omron F3SJ-A series User Manual

10
Chapter1 Ratings
F3SJ-A
User’s Manual
Overview and Specifications
Indicators Emitter Incident light level indicators (green LED x 2, orange LED x 3): ON based on the amount of
incident light
Error mode indicators (red LED x 3): Blink to indicate error details
Power indicator (green LED x 1): ON while power is ON
Lockout indicator (yellow LED x 1): Blinks when in lockout
External device monitoring indicator (muting input 1 indicator), Test indicator (muting input 2
indicator) (green LED x2): ON/Blink according to function
Receiver Incident light level indicators (green LED x 2, orange LED x 3): ON based on the amount of
incident light
Error mode indicators (red LED x 3): Blink to indicate error details
OFF-statet indicator (red LED x 1): ON when safety outputs are OFF/ Blinks when in lockout
ON-state indicator (green LED x 1): ON when safety outputs are ON
Muting error indicator, Test indicator (green LED x 2): ON/Blink according to function
Mutual interference prevention
function
Interference light avoidance algorithm
Series connection Time division emission by series connection
- Number of connections: Up to 3 sets
- Total number of beams: Up to 240
- Maximum cable length between 2 sets of sensors: 15m
Lockout occurs when:
- Number of connected sensors or total number of beams of them exceed the limits described
above
- Other sensor than -TS type is attached to the series connection
Test function - Self-test (After power ON, and during operation)
- External test (light emission stop function by test input)
Safety-related functions - External device monitoring
- Muting (Includes override functions. F39-CN6 key cap for muting is required)
Connection method Connector method (M12, 8-pin)
Protection circuit Output short-circuit protection, and power supply reverse polarity protection
Ambient temperature During operation: -10 to 55°C (without freezing), During storage: -30 to 70°C
Ambient humidity During operation: 35 to 85%RH (no condensation), During storage: 35 to 95%RH
Ambient light intensity Incandescent lamp: receiving-surface light intensity of 3,000 Ix max., Sunlight: receiving-
surface light intensity of 10,000 Ix max.
Insulation resistance 20MΩ or higher (500VDC)
Dielectric strength voltage 1, 000VAC, 50/60Hz, 1min
Degree of protection IP65 (IEC60529)
Vibration resistance Malfunction: 10 to 55Hz, Multiple amplitude of 0.7mm, 20 sweeps each in X, Y, and Z directions
Shock resistance Malfunction: 100m/s
2
, 1,000 times each in X, Y, and Z directions
Connection cable, Series connection
cable (F39-JJRL, JJR3W)
Dia. 6 mm, 8-wire (0.15mm
2
x 8) with braided shield, Allowable bending radius R5mm
Extension cable (F39-JCA,
JCB,JCC)
Dia. 6.6 mm, 8-wire (0.3mm
2
x 4P, conductor resistance 0.058 ohm/m), with braided shield,
Allowable bending radius of R36mm.
(To extend a cable, use an equivalent or higher-performance cable (twisted-pair wire) , and do
not use the cable in the same duct as that for high-voltage cables or power cables)
For details about extension lengths (power cable length) p.15
For details about twisted pair wire (single connector cable)
p.86
Material Casing (including metal parts on both ends): Aluminum, zinc die-cast
Cap: ABS resin
Optical cover: PMMA resin (acrylic)
Cable: Oil resistant PVC
F3SJ-AP20-TS F3SJ-AP25-TS
