15
F3SJ-A
User’s Manual
Chapter1 Ratings
Overview and Specifications
E
Power Cable Length
Extension of power cable must be the length shown below or shorter:
In case F3SJ is directly connected to external power supply, or connected to G9SA-300-SC
When connected to F3SP-B1P
Extension of the cable must be within a specified length. If it isn't, safety function may not work
properly, resulting in danger.
Condition Single 2 connected 3 connected
Incandescent display lamps are used by auxiliary output
and/or external indicator output
45m 40m 30m
Incandescent display lamps are not used 100m 60m 45m
Condition Single 2 connected 3 connected
Incandescent display lamps are - used by external
indicator output 2
40m 30m 25m
Incandescent display lamps are
- used by external indicator output 1and/or,
- used by auxiliary output 1
60m 45m 30m
Incandescent display lamps are not used 100m 60m 45m
Courtesy of CMA/Flodyne/Hydradyne ▪ Motion Control ▪ Hydraulic ▪ Pneumatic ▪ Electrical ▪ Mechanical ▪ (800) 426-5480 ▪ www.cmafh.com
